Camera IP hồng ngoại 4.0 Megapixel HILOOK IPC-B140H-M

Camera IP hồng ngoại 4.0 Megapixel HILOOK IPC-B140H-M

- Cảm biến hình ảnh: 1/3-inch Progressive Scan CMOS.

- Độ phân giải camera ip: 4.0 Megapixel.

- Ống kính: 2.8mm, 4mm, 6mm.

- Tầm quan sát hồng ngoại: 30 mét.

- Chuẩn nén hình ảnh: H.265+/H265/H.264+ & H.264.

- Hỗ trợ 2 luồng dữ liệu.

- Hỗ trợ chức năng chống ngược sáng WDR 120dB.

- Hỗ trợ chức năng giảm nhiễu số 3D DNR, bù sáng BLC.

- Chế độ ngày/đêm: Đặt theo lịch, tự động, ngày, đêm.

- Hỗ trợ giám sát bằng ứng dụng HiLook trên điện thoại.

- Không hỗ trợ khe cắm thẻ nhớ.

- Tiêu chuẩn chống bụi và nước: IP67 (Thích hợp sử dụng trong nhà và ngoài trời).

- Nguồn điện: DC12V.

- Chức năng cung cấp nguồn qua Ethernet (PoE).

Đặc tính kỹ thuật

Camera
Image Sensor	1/3-inch progressive scan CMOS
Min. Illumination	Color: 0.01 Lux @(F1.2, AGC ON), 0.028 Lux @ (F2.0, AGC ON)
Shutter Speed	1/3s to 1/100,000s
Slow Shutter	Yes
Day &Night	IR cut filter
DNR (Digital Noise Reduction)	3D DNR
WDR (Wide Dynamic Range)	120 dB
Angle Adjustment(Bracket)	Pan: 0° to 360°, tilt: 0° to 180°, rotation: 0° to 360°
Lens
Focal Length	2.8mm, 4mm, 6mm
Aperture	F2.0
FOV	2.8 mm, horizontal FOV 100°, vertical FOV 55°, diagonal FOV 117° 4 mm, horizontal FOV 77°, vertical FOV 42°, diagonal FOV 88° 6 mm, horizontal FOV 51°, vertical FOV 28°, diagonal FOV 58°
Lens Mount	M12
IR
IR Range	Up to 30 m
Wavelength	850 nm
Compression Standard
Video Compression	Main stream:H.265/H.264 Sub stream: H.265/H.264/MJPEG
H.264 Type	Baseline Profile/Main Profile/High Profile
H.264+	Main stream supports
H.265 Type	Main Profile
H.265+	Main stream supports
Video Bit Rate	32 Kbps to 8 Mbps
Smart Feature-set
Region of Interest	1 fixed region for main stream and sub-stream
Max. Resolution	2560 × 1440
Main Stream Max. Frame Rate	50Hz: 20fps (2560 × 1440), 25fps (2304 × 1296, 1920 × 1080, 1280 × 720) 60Hz: 20fps (2560 × 1440), 30fps (2304 × 1296, 1920 × 1080, 1280 × 720)
Sub-stream Max. Frame Rate	50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Image Enhancement	BLC, 3D DNR
Image Settings	Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser
Day/Night Switch	Auto, scheduled
Network
Network Storage	NAS (NFS, SMB/CIFS)
Alarm Trigger	Motion detection, video tampering alarm, illegal login
Protocols	TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6UDP, Bonjour
General Function	Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
Firmware Version	5.5.3
API	ONVIF (PROFILE S, PROFILE G), ISAPI
Simultaneous Live View	Up to 6 channels
User/Host	Up to 32 users 3 levels: Administrator, Operator, and User
Client	iVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500
Web Browser	IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+
Interface
Communication Interface	1 RJ45 10M/100M self-adaptive Ethernet port
General
Operating Conditions	-30 °C to 50 °C (-22 °F to 122 °F), humidity: 95% or less (non-condensing)
Power Supply	12 VDC ± 25%, 5.5 mm coaxial power plug PoE (802.3af, class 3)
Power Consumption and Current	12 VDC, 0.4 A, Max: 5 W PoE: (802.3af, 36 V to 57 V), 0.2 A to 0.13 A, Max: 7 W
Protection Level	IP67
Material	Front cover: metal, camera body: metal, bracket: metal
Dimensions	Camera: Ø 70 mm × 191.3mm (Ø 2.7' × 7.5') With package: 216 mm × 121 mm × 118 mm (8.5' × 4.8' × 4.6')
Weight	Camera: approx. 402 g (0.9 lb.) With package: approx: 641 g (1.4 lb.)
